Bioclimatic pergola ACURA Q25 Premium
STRUCTURE DESCRIPTION
ACURA Q25 Bioclimatic Modular Aluminum Louvered Pergola – a modern terrace system designed to protect open spaces of cafes, bars, restaurants, hotels, and private homes from sun, rain, and wind.
Technical Specifications:
  • Maximum Projection per Module – 9 000 mm
  • Maximum Width per Module – 4 000 mm
  • The number of modules is unlimited
  • Snow Load Capacity – 220-250 kg/m²
  • Opening Type – Automatic synchronized rotating sliding louver opening
  • Opening Mechanism – Scissor-macross Euro standard
  • Model – PREMIUM
  • Easy installation, assembles in 4 hours
  • Control – Remote (handheld)
  • Integration with "Smart Home" ecosystem
  • Fully sealed system
TECHNICAL SPECIFICATIONS
SYSTEM PROFILES
Louver – Hilam 310 mm
Post size – 220*120 mm
The thickness of the aluminum frame is 3.5–5 mm
Panel profile thickness – 38 mm
Motor – Somfy (France)
Fasteners made of impact-resistant, stainless steel INOX
Built-in drainage system for water runoff
Seals between the louvers
RECOMMENDED RETAIL PRICE
for the finished structure

ACURA Q25 Premium
Freestanding structure

Projection: 9000 mm
Width: 4000 mm
Height: 3000 mm

LED lighting – Samsung
Motor – Somfy (France)
Somfy 1-channel remote control
$33 160
р.
Get DEALER discount %
LED Lighting System
The system features two rows of lighting:
  • LED panel lighting – RGB Samsung
  • LED space lighting – Linear LED Samsung
Lighting control – remote controller with a touch wheel for color selection

Depending on the client's preferences, design project specifications, and installation conditions, one or both lighting options can be selected
LOUVER MOVEMENT MECHANISM
The ACURA Q25 Premium bioclimatic pergola by ALUMINANTE features a pivot-sliding louver opening mechanism, where the louvers operate as a unified system, smoothly rotating and sliding simultaneously. This principle resembles the movement of scissors, ensuring precise light and airflow regulation, as well as a tight closure for complete sealing.

Aluminum louvers rotate 75 degrees and slide, leaving 85% of the opening unobstructed
The Hilam 310 mm louver allows for 85% of the opening to be exposed, providing ventilation and optimal airflow and light, as well as a stunning panoramic view. When closed, they serve as protection against precipitation, solar radiation, cold air, debris, insects, and noise
CONSTRUCTION OPTIONS
Depending on the project, customer preferences, and installation requirements, the system can be:

  • Freestanding
  • Wall-mounted
  • Suspended
  • Frame-mounted without posts
integration options
Depending on the project requirements, client preferences, and installation details, the ACURA Q25 Premium system can be successfully integrated with other solutions from ALUMINANTE. This allows for a cohesive design and the ability to purchase all necessary products from a single reliable supplier
Products from ALUMINANTE compatible with ACURA Q27 Twist:
  1. Orizzonte, Orizzonte Thermo, Spazio, Aspetto slide glazing
  2. Skyline automatic guillotine glazing
  3. Agio lift-and-slide doors
  4. Piega folding doors
  5. Vito Zip automatic sun protection system
ADDITIONAL OPTIONS
This structure supports integration with the "Smart Home" system, allowing for automated control through digital applications. With the TAHOMA app, which manages devices equipped with a SOMFY RTS motor, you can control the system directly from your smartphone or tablet, ensuring maximum convenience and control at any time
Additionally, it is possible to install:
  • Lighting
  • Heaters
  • Audio systems
  • Fans
  • Retractable TV screens
